New model Extasy

Evolution electric modification

Checkout on Evolution electric modification.

Performance analysis

We have calculated the performance of the Evolution V-Tail model using the XFoil program. We hope that this knowledge will allow better settings for your model and will contribute to improving the properties for a new model. We plan to compare the calculated results with the actual parameters of the model using a barometric altimeter and GPS logger as soon as possible. So far, however, the results appear to be remarkably accurate (for example minimum sink rate).

Results were calculated for a model weight from 2200 grams to 3400 grams with 400 grams resolution. It appears that for distance and speed task, more weight means a better outcome. The graphs also show the maximum glide ratio and maximum flight efficiency. For distance task it is good to move between the maximum of these variables. For Evolution model the trim speed is almost the same as the speed for maximum glide ratio. All calculations are for a model with control surfaces (v-tail, elevator, ailerons, flaps) in neutral position. Later we compute also optimum flaps angle for achieve maximum lift for start on winch and appropiate elevator correction.

Integrated v-tail bowden

34. Oktoberfestpokal 2009 in München

Congratulations to Günter Aichholzer with Evolution to 9th place - 97,41% to winner and 4th in SPEED task from 120 competitors in F3B competition 34. Oktoberfestpokal 2009. More info on www.f3b.de.

Plassenburgpokal 2009 in Kulmbach

Congratulations to Stefan Sporer (5th place - 97,94% to winner) and Günter Aichholzer (12th place - 95,43% to winner) in F3B competition Plassenburgpokal 2009. More info on www.f3b.de.

F3B World Cup - Ivancice, Distance

Jiri Tuma flight Distance task on F3B World Cup with Evolution V, total 29 laps (winner - 30 laps). Below is altitude log from this flight. According statistics, start in 360 meters, 12.5 vertical meters and 8.2 seconds on each lap.

Altitude logs

Jiri Tuma training flights, altitude logs - 10.6.2009 Maximum is 343 meters! Average cca 300 meters. Wind aprox. 4-5 m/s.

F3x color desinger

JITOM offer new tool for custom color desing. You may configure any color combination you want in four diferent views. Online in you browser, instalation is not require. It's simple, just try...

Evolution V-tail desinger
Evolution X-tail desinger
